High-Speed Stamping CH-45 Lunch Box Punching Press Machine
USD 14400,00 – 15000,00
/ piece
Il prezzo varia per quantità e specifiche
| Q.tà min. | 1 piece |
| Categoria | Machinery |
9
Anni
98%
Tasso risposta
24h
Tempo risposta
Altro da questo fornitore
Descrizione prodotto
Nessuna descrizione disponibile. Invia una richiesta per maggiori informazioni.
Specifiche tecniche
| Model NO. | CH Series |
| After-sales Service | One-Year Warranty |
| Warranty | One-Year Warranty |
| Application | Metal |
| Process Usage | Metal-Cutting CNC Machine Tools, Metal-Forming CNC Machine Tools |
| Movement Method | Linear Control |
| Control Method | Open-Loop Control |
| Numerical Control | CNC/MNC |
| Processing Precision | 0.05~0.06(mm) |
| Performance Classification | Economical CNC Machine Tools |
| Certification | CE, ISO 9001 |
| Condition | New |
| Product Name | Food Container Tray Punching Machine |
| Keywords | Punching Machine |
| Model | CH-45/CH-63/CH-80 |
| Norminal Pressure (kN) | 450/630/800 |
| Norminal Pressure Stroke (mm) | 4 |
| Slider Stroke (mm) | 220/240/280 |
| Stroke Times (Min) | 40-70 |
| Max Mold Height (S.P.M) | 450/500 |
| Mold Height Adjustment (mm) | 60/80 |
| Worktable Size (mm) | 800X900/1100X1100/1460X900 |
| Worktable Plate Thickness (mm) | 110/130 |
| Top Worktable Size (mm) | 340X410/580X400/750X520 |
| Motor Power (Kw) | 5.5/7.5/11 |
| Weight (Kg) | 5000/8000/11500 |
| Transport Package | Standard Packaging or Customized |
| Specification | Standard Specifications or Customized |
| Trademark | JBLDY |
| Origin | Shandong, China |
