Large Scale CNC Bending Press with 6000mm Table Length for Shipbuilding and Construction
Thumbnail 1 Thumbnail 2 Thumbnail 3 Thumbnail 4 Thumbnail 5 Thumbnail 6
Manufacturer & Trading Company

Large Scale CNC Bending Press with 6000mm Table Length for Shipbuilding and Construction

USD 15250,00 – 53334,00 / piece
Il prezzo varia per quantità e specifiche
Q.tà min. 1 piece
Categoria General
Invia ordine
Shanghai Ants Machine Equipment Co., Ltd.

China

Manufacturer & Trading Company
26
Anni
98%
Tasso risposta
24h
Tempo risposta
Chatta ora
Altro da questo fornitore
Heavy Duty Sheet Metal Press Brake with 18.5kw Main Motor for Continuous Operation
Heavy Duty Sheet Metal Press Brake with 18.5kw Main Motor for Continuous Operation
USD 15800,00
Hydraulic Sheet Metal Brake with 60mm/S RAM No Load Speed for High Productivity Bending
Hydraulic Sheet Metal Brake with 60mm/S RAM No Load Speed for High Productivity Bending
USD 15800,00
High Torque CNC Bending Press with 300 Ton Force and 2600mm Column Distance
High Torque CNC Bending Press with 300 Ton Force and 2600mm Column Distance
USD 15800,00
Industrial CNC Hydraulic Press Brake with 800mm Backgauge Stroke for Large Workpiece Positioning
Industrial CNC Hydraulic Press Brake with 800mm Backgauge Stroke for Large Workpiece Positioning
USD 15800,00
CNC Hydraulic Press Brake with Torsion Bar Synchronization for Parallel RAM Movement
CNC Hydraulic Press Brake with Torsion Bar Synchronization for Parallel RAM Movement
USD 15800,00
Heavy Duty Metal Bending Press with 50mm/S RAM Return Speed for Efficient Cycle Times
Heavy Duty Metal Bending Press with 50mm/S RAM Return Speed for Efficient Cycle Times
USD 15800,00

Descrizione prodotto

Nessuna descrizione disponibile. Invia una richiesta per maggiori informazioni.

Large Scale CNC Bending Press with 6000mm Table Length for Shipbuilding and Construction
Large Scale CNC Bending Press with 6000mm Table Length for Shipbuilding and Construction

Specifiche tecniche

Model NO.WC67K-500T6000
After-sales ServiceOne Year
Waterproof RatingIPX-8
Warranty1-year
ConditionNew
CertificationISO 9001:2000, ISO 9001:2008, CE
AutomationAutomatic
Suitable forCopper, Aluminum, Alloy, Carbon Steel, Stainless Steel
TypeHydraulic Bending Machine
NamePress Brake Machine
ModelWe67K- 500t/ 6000
Nominal Pressure5000 kN
Bending Length6000 mm
Distance Between Columns4500 mm
Maximum Opening Height600 mm
Back Gauge X Axis(800 mm,400 mm/S,±0.5 mm,±0.3mm)
Slider Y1 Y2 Axis(400 mm,±0.5 mm,±0.5 mm)
Slider Running Speed(60mm/S,6 mm/S,48 mm/S)
Number of CNC Axes3+1 Axes [ Y1 Y2, X, V]
Motor Power37 Kw
Machine Dimensions6500*2550*4500
Transport PackageFactory Standard Packing
Specificationcustomization
TrademarkANTISHICNC
OriginChina
